Fibral Multiflex Baffle

معلومات عامة

Description
Fibral and Opal are vertically installed baffles with a smooth surface enabling creative design solutions and acoustic control. Developed to meet the exacting standards of health, electronics and food sectors, durable Hygienic baffles can withstand cleaning by pressure washing.
Fibral Multiflex Baffle is supplied with steel cappings which are right angled U-sections with punched holes and built-in clips makes the baffle suitable for different installation methods.

Acoustics – Sound Absorption
Sound absorption has been measured in accordance with ISO 354. The sound absorption properties of items such as islands or baffles are quantified by the equivalent sound absorption area expressed as m² per item. This is the area of a 100% absorbing surface which would absorb the same amount of sound as the item in question.

Fire Performance
Rockfon ceiling tiles have a core of stone wool. Stone wool is noncombustible with a melting point of more than 1000°C.
The fire resistant properties of stone wool ensure Rockfon ceiling tiles provide fire protection in construction. The fire protection properties of Rockfon ceilings have been tested and classified in accordance with European norm EN 13501-2 and/or national norms depending on requirements in national building codes.

Humidity Resistance And Dimensional Stability (Flexural Tensile Strength)
Rockfon Fibral Baffles are dimensionally stable even at humidity levels of up to 100% RH and can be installed at all temperatures ranging from 0ºC to 40°C.
No acclimatisation is necessary.

Light Reflection
White, 77% diffuse light reflection in accordance with ISO 7724-2.

Cleaning
The surface can be vacuum cleaned with a soft brush attachment.The surface can also be cleaned once a week using a sponge or cloth and warm water (max. 40°C) with a slightly alkaline detergent (max. pH 10) without alcohol, ammonia or chlorine. Cleaning with a damp sponge or cloth may render the surface slightly shinier and we therefore recommend cleaning the whole surface evenly for best results.

Hygiene
Stone wool has no nutritional value and therefore it provides no sustenance to harmful micro-organisms.

Clean Room Classification
Hygienic Baffles are classified as Class 5 in accordance with ISO 14644-1.

Environment
A representative selection of Rockfon products have been awarded the Indoor Climate Label and the Finnish Indoor Climate Label (M1).Rockfon Baffles are recyclable.
