Medicare Plus

معلومات عامة

Description
Acoustic ceiling panel that fulfils stringent hygiene requirements in healthcare environments.
MediCare Plus is recommended for areas with more stringent hygiene and cleaning/disinfection requirements, such as accident and emergency rooms, delivery rooms, small surgery, radiology, laboratories and corridors. It offers the highest sound absorption value in the market. MediCare Plus has obtained a Bacteriological Class B1, beyond the requirements of the very high risk zones as defined in NF S 90-351. MediCare Plus does not contribute to the growth of MRSA. It has a low particle emission resulting in Clean Room Classification ISO Class 5. Medicare Plus offers design freedom to architects thanks to its concealed edges and a range of corridor dimensions. It has sealed edges and a water repellent surface that is resistant to the most common detergents and disinfectants, but can also be effectively disinfected by steam cleaning.

MediCare Plus is an acoustic ceiling made of a 20-25 mm stone wool panel. The visible surface is covered with a white painted water repellent fleece providing an aesthetically pleasing finish and ease of cleaning. The rear side of the panel is covered by a back fleece. The edges are sealed.

Acoustics – Sound absorption
Sound absorption has been measured in accordance with ISO 354. Sound absorption data ap, aw and absorption class are calculated in accordance with ISO 11654. Noise Reduction Coefficient (NRC) is calculated in accordance with ASTM C423.
The best sound absorption :
αw: 1.00 and NRC: 0.95

Fire Performance
General:
Rockfon ceiling tiles have a core of stone wool. Stone wool is noncombustible with a melting point of more than 1000°C.
Reaction to fire:
Class A1 in accordance with EN 13501-1.
Fire protection:
The fire resistant properties of stone wool ensure Rockfon ceiling tiles provide fire protection in construction. The fire protection properties of Rockfon ceilings have been tested and classified in accordance with European norm EN 13501-2 and/or national norms depending on requirements in national building codes.

Humidity Resistance And Dimensional Stability (Flexural Tensile Strength)
Rockfon ceiling tiles are dimensionally stable even at humidity levels of up to 100% RH and can be installed at all temperatures ranging from 0ºC to 40°C.
No acclimatisation is necessary.
Medicare Plus is predominantly classified as Class 1/C/0N in accordance with EN 13964. However, certain module sizes (width above 700mm) are Class 2/C/0N.

Light Reflection
White, 85% diffuse light reflection in accordance with ISO 7724-2.

Cleaning
The surface of MediCare Plus has enhanced resistance and is highly water-repellent. It is treated to minimise dirt pick-up and finger marking – this being essential for ease of installation and frequent demounting for access to services. The surface can be vacuum cleaned with a soft brush attachment and it resists diluted solutions of the following: ammonia, chlorine, quaternary ammonium and hydrogen peroxide. Cleaning with a sponge or damp cloth may render the surface slightly shinier and we therefore recommend cleaning the whole surface evenly for best results.
MediCare Plus can also be cleaned and disinfected twice a year by steam cleaning following a protocol defined by experts and using an adapted surface mop.K

Hygiene
Rockfon A Kenar Paneller demonte edilebilir. Samson sistemi ile kullanilan paneller demonte degildir.

Temizleme
Yüzey vakumlu yumusak bir firça ile yilda 52 defa temizlenebilir.

Hijyen
Stone wool has no nutritional value and therefore it provides no sustenance to harmful micro-organisms.
MediCare Plus has been tested with the following micro-organisms and has obtained the bacteriological class B1, which is beyond the requirements of Zone 4 as defined in NF S 90-351:
– Methicillin Resistant Staphylococcus Aureus (MRSA): bacteria resistant to antibiotics and responsible for post-surgery infections and septicaemias.
– Candida Albicans: yeast responsible for skin infections and pneumonias.
– Aspergillus Niger: mould responsible for pneumonias.
MediCare Plus can be effectively disinfected by steam cleaning. The bactericidal and fungicidal effect of steam cleaning on MediCare Plus has been tested. It meets the requirements of NF EN 14561 (> 5 log10) and NF EN 14562 (> 4 log10), meaning the disinfection is very effective.

Aftercare
The tiles can be treated with Rockfon finishing paint, PVA water-based special paint with safety code 00-1, applied in the correct amount with an airless spray with good capacity. The surface of the tiles must be clean and dry and the existing paint surface must be firmly adhered to the tile prior to refinishing.Heavily discoloured tiles should be replaced.The painting of acoustic tiles reduces the sound absorption by approximately 10%.

Environment
A representative selection of Rockfon products have been awarded the Indoor Climate Label and the Finnish Indoor Climate Label (M1).MediCare is recyclable.
